CTB810 HN800 电容式接近开关能够感测到微小的电容变化

宽检测范围:由于其非接触特性,电容式接近开关可以检测非金属或不同介电常数的物体,甚至可以检测液体。

低功耗:由于其工作原理,电容式接近开关的功耗相对较低,适合于需要长时间稳定运行的应用。

响应速度快:电容式接近开关的响应速度很快,能够快速地检测物体的接近和离开。

分类: ,
  • 购买咨询热线/Phone:18859254943
  • 邮箱/Email:sales@ygdcs.com
  • 地址:成都高新区天益街北巷52号附14号2层

描述

CTB810 HN800 电容式接近开关能够感测到微小的电容变化

电容式接近开关是一种非接触式的位置传感器,CTB810 HN800 其测量头通常是构成电容器的一个极板,而另一个极板是物体的本身。当物体移向接近开关时,物体和接近开关的介电常数发生变化,使得和测量头相连的电路状态也随之发生变化,由此便可控制开关的接通和关断。这种接近开关的检测物体,并不限于金属导体,也可以是绝缘的液体或粉状物体。

电容式接近开关具有无抖动、无触点、非接触检测等优点,其抗干扰能力、耐蚀性能等比较好。在检测较低介电常数ε的物体时,可以顺时针调节多圈电位器(位于开关后部)来增加感应灵敏度。电容式接近开关理论上可以检测任何物体,当检测过高介电常数物体时,检测距离要明显减小。

此外,电容式接近开关的接通时间为50ms,所以在用户产品的设计中,当负载和接近开关采用不同电源时,务必先接通接近开关的电源。

CTB810 HN800 电容式接近开关具有多个优点:

高灵敏度和精度:由于其工作原理基于电容变化,电容式接近开关能够感测到微小的电容变化,具有非常高的灵敏度。这使得它们能够更精准地检测物体的接近情况。

非接触式检测:电容式接近开关不需要与被检测物体直接接触,从而避免了机械磨损,延长了使用寿命。

宽检测范围:由于其非接触特性,电容式接近开关可以检测非金属或不同介电常数的物体,甚至可以检测液体。

低功耗:由于其工作原理,电容式接近开关的功耗相对较低,适合于需要长时间稳定运行的应用。

响应速度快:电容式接近开关的响应速度很快,能够快速地检测物体的接近和离开。

稳定性高:由于其高稳定性,电容式接近开关在各种环境条件下都能保持稳定的性能。

易于集成:电容式接近开关易于与其他电子设备集成,使用方便,能够提高整个系统的自动化程度。

综上所述,CTB810 HN800 电容式接近开关具有高灵敏度、高精度、非接触式检测、宽检测范围、低功耗、响应速度快、高稳定性和易于集成等优点。因此,它们在许多领域都有广泛的应用,如机器人技术、自动化生产线、物流系统、安全防护系统等。

CTB810 HN800 电容式接近开关能够感测到微小的电容变化

The capacitive proximity switch is a non-contact position sensor, the CTB810 HN800 whose measuring head is usually one plate that constitutes the capacitor, and the other plate is the object itself. When the object moves towards the proximity switch, the dielectric constant of the object and the proximity switch changes, so that the state of the circuit connected to the measuring head also changes, so that the switch can be controlled on and off. The detection object close to the switch is not limited to a metal conductor, but can also be an insulating liquid or powdery object.

Capacitive proximity switch has the advantages of no jitter, no contact and non-contact detection, and its anti-interference ability and corrosion resistance are better. When detecting objects with low dielectric constant ε, the multi-turn potentiometer (located at the rear of the switch) can be adjusted clockwise to increase the sensitivity. The capacitive proximity switch can detect any object in theory, and the detection distance should be significantly reduced when detecting objects with too high dielectric constant.

In addition, the turn-on time of the capacitive proximity switch is 50ms, so in the design of the user’s product, when the load and the proximity switch use different power supplies, it is necessary to first turn on the power supply of the proximity switch.

The CTB810 HN800 Capacitive proximity switch offers several advantages:

High sensitivity and accuracy: Because its working principle is based on capacitance changes, capacitive proximity switches can sense small capacitance changes and have very high sensitivity. This allows them to more accurately detect an object’s approach.

Non-contact detection: Capacitive proximity switches do not require direct contact with the object being detected, thereby avoiding mechanical wear and extending service life.

Wide detection range: Due to its non-contact nature, capacitive proximity switches can detect non-metals or objects with different dielectric constants, and can even detect liquids.

Low power consumption: Due to its operating principle, capacitive proximity switches have a relatively low power consumption and are suitable for applications that require stable operation for long periods of time.

Fast response speed: The response speed of the capacitive proximity switch is fast, and it can quickly detect the approach and departure of the object.

High stability: Due to its high stability, capacitive proximity switches maintain stable performance under various environmental conditions.

Easy integration: Capacitive proximity switches are easy to integrate with other electronic devices, easy to use, and can improve the degree of automation of the entire system.

In summary, the CTB810 HN800 capacitive proximity switch has the advantages of high sensitivity, high precision, non-contact detection, wide detection range, low power consumption, fast response speed, high stability and easy integration. Therefore, they are widely used in many fields, such as robotics, automated production lines, logistics systems, and security protection systems.
