2711PC-T10C4D8 PanelView Plus 6 600 紧凑型终端

描述

2711PC-T10C4D8   PanelView Plus 6 600 紧凑型终端

2711PC-T10C4D8 PanelView Plus 6是Allen-Bradley的紧凑型图形终端。凭借其紧凑的设计和固定的配置，它是一个流行的艾伦-布拉德利HMI(人机界面)为CompactLogix控制器。2711PC-T10C4D8具有一个RS-232串口、一个以太网端口和2个支持串行和以太网通信的USB端口。2711PC-T10C4D8终端配备10.4英寸彩色有源矩阵TFT，带有电阻式触摸输入。显示器分辨率为640 x 480像素，具有18位彩色图形。它重5.6磅，尺寸为9.77 x 12.97 x 2.18英寸。2711PC-T10C4D8具有512 MB非易失性闪存和512 MB RAM。它还支持用于外部存储的安全数字(SD)卡。

2711PC-T10C4D8端子的直流输入电压为18 ~ 30v DC(标称24v DC)，最大功耗为70w。对于安装，它可以面板安装NEMA/UL类型12,13,4x和IP54或IP65额定外壳。通过ActiveX控件、备份恢复和远程连接等附加功能，它为用户提供了极大的灵活性。各种外部设备，如鼠标或键盘可以连接到它。2711PC-T10C4D8是Allen-Bradley PanelView Plus 6紧凑型终端。2711PC-T10C4D8 PanelView Plus 6紧凑型终端具有8.3 x 6.2英寸彩色显示屏和触摸屏输入。

这个人机界面通过彩色编码显示和动画支持高信息量图形的设计。它可以配置为遵循国际颜色标准，以指示设备，设备和过程或机器的运行状态。

该人机界面由24VDC输入电源供电。建议采用外部保护，避免损坏硬件。该操作终端配备了一个嵌入式512 MB随机存取存储器(RAM)和512 MB非易失性存储器(约为1mb)。79 MB可用用户内存)。

2711PC-T10C4D8

2711PC-T10C4D8   PanelView Plus 6 600 紧凑型终端

The 2711PC-T10C4D8 PanelView Plus 6 is a compact graphics terminal by Allen-Bradley. With its compact design and fixed configuration, it is a popular Allen-Bradley HMI (human-machine interface) for CompactLogix controllers. The 2711PC-T10C4D8 has an RS-232 serial port, an Ethernet port, and 2 USB ports that support serial and Ethernet communications. The 2711PC-T10C4D8 terminal comes with a 10.4-inch color active-matrix TFT with a resistive touch input. The display resolution is 640 x 480 pixels and it has 18-bit color graphics. It weighs 5.6 pounds and measures 9.77 x 12.97 x 2.18 inches. The 2711PC-T10C4D8 has 512 MB non-volatile flash memory and 512 MB of RAM. It also supports a Secure Digital (SD) card for external storage.

The 2711PC-T10C4D8 terminal requires a DC input voltage of 18 to 30 Volts DC (24 Volts DC nominal) and it has a maximum power consumption of 70 W. For installation, it can be panel-mounted with NEMA/UL Type 12, 13, 4X, and IP54 or IP65 rated enclosures. With additional features such as ActiveX controls, backup restore, and remote connectivity, it provides great user flexibility. Various external devices such as a mouse or keyboard can be connected to it. The 2711PC-T10C4D8 is an Allen-Bradley PanelView Plus 6 Compact Terminal. The 2711PC-T10C4D8 PanelView Plus 6 Compact Terminal has an 8.3 x 6.2 inches color display with touchscreen input.

This HMI support design of highly informative graphics through color coded display and animation. It may be configured to follow international color standards to indicate operational status of a device, equipment and a process or machine.

This HMI is powered by an 24VDC input supply. External protection is recommended to prevent damage to the hardware. This operator terminal comes with an embedded 512 MB Random Access Memory (RAM) and 512 MB nonvolatile memory (approx. 79 MB free user memory).
