VPROH2B IS215VPROH2BC GE 汽轮机保护板 成都阳光熹禾

  1. 型号:IS215VPROH2BC
  2. 用途:GE Mark VI 燃气轮机控制系统的紧急涡轮保护板
  3. 主要功能:提供紧急超速保护、排气过温保护、模拟电流输入、备份同步检查保护等
分类:
  • 购买咨询热线/Phone:18859254943
  • 邮箱/Email:sales@ygdcs.com
  • 地址:成都高新区天益街北巷52号附14号2层

描述

产品细节说明:VPROH2B IS215VPROH2BC GE 汽轮机保护板

  1. 紧急超速保护
    • 该保护板通过三重冗余的VPRO板设计,确保在涡轮机超速时能够迅速、可靠地触发保护机制,防止涡轮机损坏。
  2. 排气过温保护
    • 配备有九个热电偶输入,用于监测燃气轮机的排气温度,一旦温度超过安全限值,将自动触发保护措施。
  3. 模拟电流输入
    • 提供三个模拟电流输入,用于监控其他关键参数,如压力、流量等,确保涡轮机的安全稳定运行。
  4. 备份同步检查保护
    • 该功能用于检查涡轮机的同步状态,确保其在正常工况下运行,避免因同步问题导致的故障或事故。
  5. 电源设计
    • 每个VPRO板都配有自己的电源,使用来自机柜PDM的125V直流电压,可产生5V直流电压和28V直流电压。这种设计提高了系统的可靠性和稳定性。
  6. 诊断指示灯
    • VPRO前面板配有状态指示灯,用于显示板的运行状态(如RUN、FAIL等),便于维修人员快速定位问题。

VPROH2B IS215VPROH2BC

产品详情参数 :VPROH2B IS215VPROH2BC GE 汽轮机保护板

  • 安装步骤
    1. 关闭VME I/O 处理器机架。
    2. 将V型板滑入并用手推入顶部和底部控制杆,固定板的边缘连接器。
    3. 拧紧前面板顶部和底部的自攻螺钉。
    4. 打开VME 机架并查看前面板上的诊断指示灯。
  • 配置说明
    • 根据具体的应用场景和需求,对VPROH2B IS215VPROH2BC进行必要的配置和编程,以实现所需的保护功能和监控效果。

VPROH2B IS215VPROH2BC GE  应用领域:

VPROH2B IS215VPROH2BC 是一款功能强大、可靠性高的汽轮机保护板,通过其多重保护机制和精准监控功能,为燃气轮机的安全稳定运行提供了有力保障。在电力、石化、冶金等行业中得到了广泛应用,并获得了用户的一致好评。

Product Details: VPROH2B IS215VPROH2BC GE Turbine Protection Board
Emergency overspeed protection:
The protection board is designed with triple redundant VPRO board to ensure that the protection mechanism can be quickly and reliably triggered in case of turbine overspeed, preventing turbine damage.
Exhaust over temperature protection:
Equipped with nine thermocouple inputs, it is used to monitor the exhaust temperature of the gas turbine. Once the temperature exceeds the safety limit, protective measures will be automatically triggered.
Analog current input:
Provide three simulated current inputs for monitoring other key parameters such as pressure, flow rate, etc., to ensure the safe and stable operation of the turbine.
Backup synchronization check protection:
This function is used to check the synchronization status of the turbine, ensuring that it operates under normal conditions and avoiding faults or accidents caused by synchronization issues.
Power supply design:
Each VPRO board is equipped with its own power supply, which uses 125V DC voltage from the cabinet PDM to generate 5V DC voltage and 28V DC voltage. This design improves the reliability and stability of the system.
Diagnostic indicator light:
The front panel of VPRO is equipped with status indicator lights, which are used to display the running status of the board (such as RUN, FAIL, etc.), making it easy for maintenance personnel to quickly locate problems.
Product details and parameters: VPROH2B IS215VPROH2BC GE turbine protection board
Installation steps:
Close the VME I/O processor rack.
Slide the V-shaped board in and manually push in the top and bottom control rods to secure the edge connectors of the board.
Tighten the self tapping screws at the top and bottom of the front panel.
Open the VME rack and check the diagnostic indicator lights on the front panel.
Configuration Description:
Based on specific application scenarios and requirements, configure and program VPROH2B IS215VPROH2BC as necessary to achieve the required protection functions and monitoring effects.
VPROH2B IS215VPROH2BC GE Application Fields:

VPROH2B IS215VPROH2BC is a powerful and highly reliable turbine protection board that provides strong guarantees for the safe and stable operation of gas turbines through its multiple protection mechanisms and precise monitoring functions. It has been widely used in industries such as electricity, petrochemicals, and metallurgy, and has received unanimous praise from users.
