描述
MVME1604 带有 MVME1600-001 基板、100 MHz、32 MB RAM 的 SBC
MVME1600-001底板配置:
•兼容MVME760过渡模块
PM604处理器模块配置:
•100 MHz IBM 604微处理器
•32mb DRAM
•(2)BIOS芯片已安装
•256kb二级缓存
部件编号:01-W3074F 01D
PM604处理器模块部件编号:01-W3113F 03C
特点:
双高模组/PowerPC微处理器
powerpc603或604微处理器
通过基板的两个不同分支
艾默生/摩托罗拉MVME1603 / MVME1604系列单板计算机(SBC)是配备PowerPC系列微处理器的双高VMEmodule。MVME1603配备了PowerPC 603微处理器;MVME1604有一个PowerPC 604微处理器。
MVME1603 / MVME1604系列有两个平行分支,基于两个不同版本的基板(MVME1600-001和MVME1600-011)。MVME1600-001与MVME1600-011的区别主要在于I/O处理方面;两个版本的逻辑设计是相同的。
MVME1603 / MVME1604包括:
•MVME1600-001或MVME1600-011底座板
•一个处理器/内存模块(PM603或PM604)与可选的L2缓存
•MEZLED (MEZLED)提供状态指示灯和复位/中止开关
•一个可选的PCI夹层卡(PMC)额外的多功能性
其他附件可以连接到这些模块,包括DRAM扩展卡,以及过渡模块(MVME760用于MVME1600-001基板,MVME712M用于MVME1600-011基板)。这些配件单独出售。
MVME1604 带有 MVME1600-001 基板、100 MHz、32 MB RAM 的 SBC
MVME1600-001 Base Board Configuration:
• Compatible with MVME760 Transition Module
PM604 Processor Module Configuration:
• 100 MHz IBM 604 Microprocessor
• 32 MB DRAM
• (2) BIOS Chips Installed
• 256 KB L2 Cache
Part Number: 01-W3074F 01D
PM604 Processor Module Part Number: 01-W3113F 03C
Features:
Double-High VMEmodule w/PowerPC Microprocessor
PowerPC 603 or 604 Microprocessor
Two Distinct Branches Through the Base Boards
The Emerson / Motorola MVME1603 / MVME1604 Series Single Board Computers (SBC) are a double-high VMEmodule equipped with a PowerPC Series microprocessor. The MVME1603 is equipped with a PowerPC 603 microprocessor; the MVME1604 has a PowerPC 604 microprocessor.
The MVME1603 / MVME1604 family has two parallel branches based on two distinct versions (MVME1600-001 and MVME1600-011) of the base board. The differences between the MVME1600-001 and the MVME1600-011 lie mainly in the area of I/O handling; the logic design is the same for both versions.
An MVME1603 / MVME1604 consists of:
• A MVME1600-001 or MVME1600-011 Base Board
• A processor/memory module (PM603 or PM604) with optional L2 cache
• An LED mezzanine (MEZLED) to supply status indicators and Reset/Abort switches
• An optional PCI mezzanine card (PMC) for additional versatility
Other accessories can be interfaced to these modules including DRAM expansion cards, as well as transition modules (MVME760 for the MVME1600-001 base board, and the MVME712M for the MVME1600-011 base board). These accessories are sold separately.
