6181P-15TPXPSS 投射式电容触摸屏

描述

6181P-15TPXPSS 投射式电容触摸屏

618p – 15tpxpss VersaView 1500P集成显示计算机是一款坚固耐用的工业计算机，具有集成显示和不锈钢边框，设计用于工厂环境，用于许多自动化工业应用的视觉界面，控制和维护。它提供12.1英寸彩色有源矩阵，薄膜晶体管，平面触摸显示屏，显示面积为12英寸x 9英寸，本机分辨率为1024 x 768, 16.7米颜色。6181P-15TPXPSS分别提供垂直和水平40度和600度的角度视图，并且计算机具有15ms的最小显示响应时间。它有一个英特尔酷睿双核U2500处理器，处理器速度为1.2 GHz，内存为2M L2高速缓存。它还具有双通道DDR2内存插槽，最大安装内存为4GB，它还具有2个PCI插槽，可升级为1个PCI插槽加1个PCI Express插槽。这台电脑有2个(1个可启动，1个可热插拔)紧凑型闪存插槽，安装了一个40GB的2.5英寸SATA旋转硬盘驱动器，并配有一个超薄DVD-RW/CD-RW驱动器。

6181P-15TPXPSS有1个PS/2鼠标/键盘端口，1个并口，1个DVI-I端口，4个后置USB端口，2个串行COM端口，一个音频线输入/输出，一个麦克风插槽，和一个2GB以太网/IP LAN端口。它的工作温度范围为0-55℃(32-131 of)，非冷凝相对湿度范围为10-90%，存储温度范围为-20-60℃(-4-140 of)。该计算机具有NEMA类型1,4,12和IEC ip66等级外壳，可承受15G的冲击和57-640Hz的1G振动。它的平均重量为10.7公斤(23.6磅)，尺寸约为309毫米x 410毫米x 100毫米(12.16英寸x 16.14英寸x 3.94英寸)，它可以在高达6,561英尺的高度上正常工作。

6181P-15TPXPSS 投射式电容触摸屏

The 6181P-15TPXPSS VersaView 1500P Integrated Display Computer is a rugged industrial computer with an integrated display and a stainless-steel bezel designed for use in a factory environment for the visual interface, control, and maintenance of many automated industrial applications. It offers a 12.1in color active matrix, thin film transistor, flat touch display screen, with a 12in x 9in display area and a native resolution of 1024 x 768 in 16.7M colors. The 6181P-15TPXPSS provides an angular view of 40 o and 60o vertical and horizontal, respectively, and the computer has a minimum display response time of 15ms. It has an Intel Core Duo U2500 Processor with 1.2 GHz of processor speed and a 2M L2 cache memory. It also has a dual-channel DDR2 memory slot with 4GB maximum of installed memory, and it also has 2 PCI slots that are upgradable to 1 PCI slot plus 1 PCI Express slot. The computer has 2 (1 bootable, and 1 hot-swappable) compact flash memory slots, with a 40GB 2.5in SATA rotating hard disk drive installed, and it comes with a Slim DVD-RW/CD-RW Drive.

The 6181P-15TPXPSS has 1 PS/2 mouse port/keyboard port, 1 Parallel port, 1 DVI-I port, 4 rear USB ports, 2 serial COM ports, an Audio line in/line out, a Microphone slot, and a 2GB Ethernet/IP LAN port. It has a working temperature range of 0-55 oC (32-131 oF), at 10-90% non-condensing relative humidity range, and it can be stored at a range of -20-60 oC (-4-140 oF). The computer has a NEMA Type 1, 4, 12, and IEC IP66-rated enclosure, and it is built to resist a shock of 15G and a vibration of 1G at 57-640Hz. It weighs averagely 10.7kg (23.6lb), with approximate dimensions of 309mm x 410mm x 100mm (12.16in x 16.14in x 3.94in), and it can function without de-rating at an altitude of up to 6,561 feet.
