1C31204G01 高性能可编程逻辑控制器模块

描述

1C31204G01 高性能可编程逻辑控制器模块

1C31204G01是一款冗余模块，属于PLC（可编程逻辑控制器）系统中的以太网模块。该模块具有完全自适应的以太网功能，支持10/100M的速度，并可以选择半双工或全双工模式，以及直通线或对绞线连接。除了以太网通信，它还支持SRTP、EGD和通道（Channels，包括Producer和Consumer）等通信协议，以及Modbus TCP通信协议。

该模块内置交换机，有助于减少硬件费用。其下凹的以太网接口设计保护了通讯线，增强了通信的可靠性。在安全性方面，1C31204G01支持四级密码、OEM密码保护以及程序块的View and Edit加锁等安全保护功能。未来，该模块还可能支持可配置的内存写保护，如选择限定的变量表用密码保护，或对所有内存保护，用户选择其中的变量表能被写入。

此外，1C31204G01还具备串口通讯功能，适用于RX3i PCI总线，并提供两种选择：IC695CCM002（具有2个隔离的串口）和IC695CCM004（具有4个隔离的串口）。串口间以及串口与底座间均实现隔离，支持RS-232和RS-485/422通信协议，可由软件进行设置选择。

1C31204G01模块在工业自动化控制系统中扮演重要角色，能够提供可靠、高效的通信和控制功能，适用于各种需要精确控制和通信的场合。然而，具体的配置和使用方式可能会因应用需求和场景的不同而有所差异，因此在实际应用中，建议参照产品手册和技术文档进行正确配置和使用。

请注意，不同制造商可能会生产同型号或类似型号的产品，因此在购买和使用时，请确保选择信誉良好的制造商，并遵循其提供的安装、配置和使用指南，以确保产品的性能和安全性。

1C31204G01 高性能可编程逻辑控制器模块

1C31204G01 is a redundant module that belongs to the Ethernet module in the PLC (Programmable Logic Controller) system. The module has fully adaptive Ethernet capabilities, supports 10/100M speeds, and can choose half duplex or full duplex modes, as well as straight-through or twisted-wire connections. In addition to Ethernet communication, it also supports communication protocols such as SRTP, EGD and Channels (including Producer and Consumer), as well as Modbus TCP communication protocols.

The module has a built-in switch that helps reduce hardware costs. Its concave Ethernet interface design protects the communication line and enhances the reliability of communication. In terms of security, 1C31204G01 supports four-level passwords, OEM password protection, and block View and Edit locking and other security protection functions. In the future, the module may also support configurable memory write protection, such as selecting limited variables to be password protected, or for all memory protection, the user chooses which variables can be written to.

In addition, the 1C31204G01 also has a serial communication function for the RX3i PCI bus and is available in two options: IC695CCM002 (with two isolated serial ports) and IC695CCM004 (with four isolated serial ports). Isolation between serial ports and between serial ports and bases, RS-232 and RS-485/422 communication protocols, which can be set and selected by software.

The 1C31204G01 module plays an important role in industrial automation control systems, providing reliable and efficient communication and control functions for a variety of occasions requiring precise control and communication. However, the specific configuration and usage mode may vary according to application requirements and scenarios. Therefore, you are advised to refer to the product manuals and technical documents for correct configuration and usage.

Please note that different manufacturers may produce the same model or similar models, so when purchasing and using, make sure to choose a reputable manufacturer and follow the installation, configuration and use guidelines provided by them to ensure the performance and safety of the product.
