1738-IB16DM12 A输入模块

描述

1738-IB16DM12 A输入模块

Allen-Bradley 1738-IB16DM12 ArmorPoint系列A输入模块具有16个非隔离输入，5伏的断开状态电压和1.5毫安的断开状态电流。每个输入最大传感器源电流为50毫安，每个模块最大传感器源电流为800毫安。本模块现场供电电压范围为10 ~ 28.8伏，最大28.8伏时功耗为2.7瓦。1738-IB16DM12模块在最大28.8伏时的散热为9.2英热单位(BTU) /小时，具有50伏的连续隔离电压，具有增强绝缘类型。模块自带LED指示灯，供终端用户判断模块状态，有16个黄色指示灯表示输入/输出状态，1个绿/红指示灯表示网络状态，1个绿/红指示灯表示模块状态，1个红色指示灯表示故障状态。

1738-IB16DM12模块的更通用规格包括符合IP 65、66、67和69K标准的外壳等级(标记时)和5伏75毫安的最大点总线电流。1738-IB16DM12模块的环境规格包括工作温度范围为-4 ~ 140华氏度，存储温度范围为-40 ~ 185华氏度。本模块的相对湿度范围为5% ~ 95%(无冷凝)。该模块的工作冲击额定值为30g，非工作冲击额定值为50g。它的排放等级为1类A级，符合CISPR 11标准。它的振动等级是5克，在10到50赫兹。该模块的尺寸为4.72 x 2.83 x 4.25英寸，或120 x 72 x 42毫米。它的重量为10.24盎司或290克。

1738-IB16DM12 A输入模块

The Allen-Bradley 1738-IB16DM12 ArmorPoint Series A Input Module has 16 nonisolated inputs, 5 Volts of off-state voltage, and 1.5 Milliamps of off-state current. The maximum sensor source current per input is 50 Milliamps and the maximum sensor source current per module is 800 Milliamps. This module’s field power supply voltage range is 10 to 28.8 Volts and its power dissipation is 2.7 Watts at 28.8 Volts (maximum). The 1738-IB16DM12 module has a thermal dissipation of 9.2 British Thermal Units (BTU) per hour at 28.8 Volts maximum and a continuous isolation voltage at 50 Volts with a reinforced insulation type. LED indicators are included with the module, allowing the end-users to determine the status of the module, and there are 16 yellow LEDs indicating the input/output status, 1 green/red LED indicating the network status, 1 green/red LED indicating the module status, and 1 red LED for the fault status.

More general specifications for the 1738-IB16DM12 module include an enclosure rating that meets the IP 65, 66, 67, and 69K standards (when marked) and a maximum PointBus current of 75 Milliamps at 5 Volts. The environmental specifications on the 1738-IB16DM12 module include an operating temperature range between -4 and 140 degrees Fahrenheit and a storage temperature range between -40 and 185 degrees Fahrenheit. The relative humidity range on this module is between 5 and 95% (non-condensing). This module has an operating shock rating of 30 g, with a non-operating shock rating of 50 g. It has an emissions rating of Group 1, Class A, which is compliant with the CISPR 11 standards. Its vibration rating is 5 g at 10 to 50 Hertz. This module has dimensions of 4.72 x 2.83 x 4.25 inches, or 120 x 72 x 42 millimeters. It has a weight of 10.24 ounces or 290 grams.
